The Lightolier by Signify SD5R7ESCT1W is a versatile 5-inch round LED surface-mount downlight designed to provide the clean appearance of recessed lighting without requiring a traditional recessed can or housing. Its slim, low-profile design makes it an excellent solution for ceilings with limited plenum space and for residential, multifamily, hospitality and light commercial applications.
The SD5R7ESCT1W produces 700 lumens while consuming only 11 watts and features five field-selectable color temperatures — 2700K, 3000K, 3500K, 4000K or 5000K. Installers can choose the desired color temperature at installation, allowing one fixture to accommodate everything from warm residential lighting to crisp daylight-style illumination.
Designed for 120V operation, this model features TRIAC dimming for convenient light-level adjustment when paired with an appropriate compatible LED dimmer. High 90 CRI provides excellent color rendering for natural and accurate-looking colors.
The surface-mount design installs directly to a standard junction box, making it an excellent problem-solving fixture where traditional recessed lighting is difficult or impractical. The glare-controlling lens provides comfortable, evenly distributed illumination while maintaining a clean architectural appearance.
The Lightolier SD5R7ESCT1W is ENERGY STAR certified and Title 24 listed and is designed for long-lasting, energy-efficient illumination.
KEY FEATURES
• 5-inch round LED surface-mount downlight
• 700 lumen light output
• Energy-efficient 11-watt LED design
• 5CCT field selectable
• 2700K / 3000K / 3500K / 4000K / 5000K
• 90 CRI for excellent color rendering
• 120V operation
• TRIAC dimmable
• Slim, low-profile design
• Installs on a standard junction box
• No traditional recessed can required
• Glare-controlling lens for comfortable illumination
• ENERGY STAR certified
• Title 24 listed
• White finish
• Ideal for limited ceiling/plenum space
TECHNICAL SPECIFICATIONS
Brand: Lightolier by Signify
Catalog Number: SD5R7ESCT1W
Signify Product Number: 911401836484
UPC: 190096131785
Product Type: LED Surface-Mount Downlight
Shape: Round
Nominal Size: 5 Inch
Light Output: 700 Lumens
Wattage: 11 Watts
CCT: Field Selectable – 5CCT
Color Temperatures: 2700K / 3000K / 3500K / 4000K / 5000K
CRI: 90
Voltage: 120V
Dimming: TRIAC
Finish: White
Mounting: Surface Mount / Standard Junction Box
Light Source: Integrated LED
ENERGY STAR: Certified
Title 24: Listed
Rated Life: Approximately 50,000 Hours L70
5 SELECTABLE COLOR TEMPERATURES
The SD5R7ESCT1W allows the installer to select the desired color temperature during installation:
2700K – Soft / Warm White – Creates a warm, comfortable atmosphere ideal for bedrooms, living rooms and hospitality applications.
3000K – Warm White – Provides clean, warm illumination commonly used throughout homes, apartments and hotels.
3500K – Neutral White – Balanced light that works well in both residential and commercial environments.
4000K – Cool / Neutral White – Provides crisp illumination popular in kitchens, offices, work areas and commercial spaces.
5000K – Daylight – Bright, daylight-style illumination for applications where a cooler, whiter appearance is preferred.
APPLICATIONS
Ideal for:
• Residential homes
• Apartments and condominiums
• Multifamily properties
• Hotels and hospitality
• Kitchens
• Bedrooms
• Living rooms
• Hallways
• Closets
• Offices
• Light commercial spaces
• Remodeling projects
• New construction
• Property management replacement lighting
• Ceilings with limited plenum space
INSTALLATION
The SD5R7ESCT1W is designed for surface mounting directly to a standard junction box, eliminating the need for a traditional recessed can or housing.
Its slim profile makes it particularly useful in locations where limited ceiling or plenum space makes installation of conventional recessed lighting difficult.
A support wire assists with installation, while the fixture's low-profile design creates the appearance of a modern recessed downlight once mounted.
FREQUENTLY ASKED QUESTIONS
What is the SD5R7ESCT1W?
The Lightolier SD5R7ESCT1W is a 5-inch round LED surface-mount downlight featuring 700-lumen output, 5 selectable color temperatures, 90 CRI and TRIAC dimming.
How many lumens does SD5R7ESCT1W produce?
The fixture produces 700 lumens.
How many watts does it use?
The SD5R7ESCT1W consumes approximately 11 watts.
Is the lumen output selectable?
No. This model has a fixed 700-lumen output. Its color temperature is selectable.
What color temperatures can I select?
The fixture provides five selectable settings: 2700K, 3000K, 3500K, 4000K and 5000K.
Is SD5R7ESCT1W dimmable?
Yes. This model features TRIAC dimming for use with an appropriate compatible LED dimmer.
Is this a 0-10V dimming fixture?
No. SD5R7ESCT1W is the 120V TRIAC-dimming version. The similar SD5RSLMZ10SCTUW is the universal-voltage, 0-10V Dual Select model.
What voltage does it operate on?
The SD5R7ESCT1W operates on 120V.
Does it require a recessed can?
No. This is a surface-mount downlight designed to install on a standard junction box without a conventional recessed housing.
What is the CRI?
The fixture provides 90 CRI for high-quality color rendering.
What is the Signify product number?
The Signify product number is 911401836484.
What is the UPC?
The UPC is 190096131785.
Who manufactures SD5R7ESCT1W?
The fixture is manufactured under the Lightolier brand by Signify.
