Chloride by Signify
CSEE1RWW
CSE series
LED steel exit sign
Chicago Approved
The CSE Exit Series is a Chicago code approved steel exit. Ideally suited for general purpose applications, the CSE is constructed of 20-gauge steel and can be wall, ceiling or end mounted
UL listed to standard 924.
NFPA 101 (Life Safety Code).
NFPA 70 (National Electric Code)
OSHA standards.
City of Chicago codes.
UL listed for damp locations 41°F (5°C) to 113°F (45°C).
Housing is constructed of 20 gauge steel.
Housing color is standard neutral white finish.
End and back KO’s are provided for mounting convenience.
Canopy is provided for universal (Ceiling, end, and wall) mounting.
Charge rate/power “ON” LED indicator light and push to test switch for mandated code compliance testing.
Low Voltage Battery Disconnect protects the battery from being severely damaged by deep discharge during prolonged power failures.
Emergency exit signs feature a fully automatic charger designed to recharge the battery within 24 hours.
Universal voltage 120/277VAC, 50/60Hz.
Power Consumption: All models 120/277V
maximum wattage is 4W and maximum amps is .10A/.05A.
Exit face illumination is provided by an ultra-bright, energy efficient, long lasting white LEDs that provide uniform illumination.
Uniform 6" letter illumination (3/4" stoke).
Maintenance-free sealed Lithium Ion Battery
Phosphate(LiFePO4)
Provides a minimum of 90 minutes emergency
illumination while in the emergency mode.
