The Lightolier by Signify DL3RSLMZ10SCTUW is a versatile 3-inch round LED canless downlight featuring both field-selectable lumen output and selectable color temperature. Designed for residential, hospitality and light commercial applications, this compact downlight gives installers the flexibility to select the desired light output and color temperature during installation.
The dual-select design allows the fixture to be set to either 370 or 500 lumens and provides five selectable color temperatures: 2700K, 3000K, 3500K, 4000K or 5000K.
The DL3RSLMZ10SCTUW operates on universal 120-277V input and uses only 6W or 8W, depending on the selected lumen setting.
Unlike traditional recessed lighting that requires a recessed can or housing, this canless LED downlight uses a detachable junction box, simplifying installation and making it an excellent solution for both new construction and remodeling applications.
The fixture features 0-10V dimming for commercial and residential lighting-control applications and offers high-quality illumination with 90+ CRI for accurate, natural-looking color.
Its low-profile design allows installation in areas where ceiling space is limited and traditional recessed housings may not be practical.
With an estimated L70 life of 50,000 hours, ENERGY STAR certification, IC rating, damp-location rating and a 5-year limited warranty, the Lightolier DL3RSLMZ10SCTUW provides a flexible and energy-efficient recessed lighting solution.
One fixture gives you five different white-light choices:
2700K – Soft/Warm White
Warm residential-style illumination ideal for bedrooms, living rooms, restaurants and hospitality environments.
3000K – Warm White
Clean warm lighting commonly used in homes, hotels, restaurants and residential spaces.
3500K – Neutral White
A balanced color temperature suitable for residential and commercial environments.
4000K – Cool/Neutral White
Crisp illumination frequently used in offices, kitchens and commercial spaces.
5000K – Daylight
Bright daylight-style illumination for applications where a whiter, more energetic appearance is preferred.
The DL3RSLMZ10SCTUW also allows the installer to select the desired light output.
370 Lumens – 6 Watts
or
500 Lumens – 8 Watts
This dual-select capability allows one SKU to handle multiple lighting requirements and can help distributors, contractors and property managers reduce the number of different fixtures they need to stock.
The Lightolier DL3RSLMZ10SCTUW is a 3-inch round canless LED downlight featuring field-selectable lumen output and five selectable color temperatures.
The fixture provides two selectable lumen settings:
370 lumens or 500 lumens.
The fixture uses approximately 6 watts at the lower lumen setting and 8 watts at the higher setting.
The fixture offers five selectable CCT settings:
2700K, 3000K, 3500K, 4000K and 5000K.
Yes. The fixture is designed with a field-selectable CCT feature. The desired color temperature can be selected during installation and can be changed later by accessing the selector.
Yes. The DL3RSLMZ10SCTUW provides selectable 370-lumen and 500-lumen output settings.
Yes. This particular Z10 model is designed for 0-10V dimming.
No. The DL3RSLMZ10SCTUW uses 0-10V dimming. Buyers should use a compatible 0-10V dimmer/control system.
The DL3RSLMZ10SCTUW operates on universal 120-277V AC input.
No. This is a canless LED downlight and does not require a conventional recessed lighting housing.
The Lightolier Dual Select downlight system uses a detachable junction box for easy canless installation.
Yes. It is IC rated for applications where the fixture may come into contact with ceiling insulation.
No. The manufacturer's documentation lists this fixture for damp locations. It should not be advertised as wet-location rated.
Because the fixture is damp-location rated, it can be suitable for appropriate damp indoor areas. It should not be represented as approved for locations requiring a wet-location-rated fixture.
The DL3RSLMZ10SCTUW provides 90+ CRI, delivering high-quality color rendering and natural-looking illumination.
The fixture has an L70 rated life of approximately 50,000 hours.
Yes. The DL3RSLMZ10SCTUW is ENERGY STAR certified.
The Lightolier Dual Select downlight family is listed as Title 24 / JA8 compliant.
The fixture has a white finish.
Typical applications include:
The fixture is sold under the Lightolier brand by Signify.
The Signify model number is 911401837684.
The catalog number identifies this specific Lightolier Dual Select configuration:
DL – Downlight Dual Select
3R – 3-Inch Round
SLM – Selectable Lumen Output
Z10 – 0-10V Dimming
SCT – Selectable Color Temperature
U – Universal Voltage
W – White Finish
The Lightolier DL3RSLMZ10SCTUW is an excellent choice for:
